| PicoCore™MX93-V5I-LIN/ W11 | |
| Status | Production |
| CPU | - |
| Typ | NXP i.MX 93 |
| Kern | ARM Cortex-A55 Cortex-M33 NPU |
| Anzahl Kerne | 2x A55 + M33 |
| Frequenz | 1.7GHz + 250MHz |
| L2-Cache | 2x64kB L2 + 256kB L3 |
| NPU | 0.5 TOPS |
| GPU | PXP |
| Security | - |
| Secure Element | Edgelock Secure Enclave |
| Betriebssystem | - |
| Linux | Yocto (uboot installed) |
| Windows | 11 IoT Enterprise (UEFI installed) |
| Echtzeit | FreeRTOS |
| Speicher | - |
| Flash | EEPROM |
| eMMC | 64GB |
| RAM | 2GB LPDDR4 |
| Schnittstellen | - |
| SD-Karte | 2x SDIO |
| Ethernet | 2x 100/1000 Mb |
| WLAN | - |
| BT | - |
| USB Host | 1x 2.0 |
| USB Device | 1x OTG 2.0 |
| CAN | 2x CAN-FD |
| UART | 8x |
| I2C | 6x |
| SPI | 8x |
| Audio | Line In/ Out/ Mic/ Headphone |
| Digital I/O | |
| ADC | 4x |
| Touch Panel | via I2C or USB |
| Kamera | MIPI-CSI (2 lanes) |
| RTC | PCF85263ATL |
| sonstige Schnittstellen | max. 4x PWM, SPDIF, ESAI, SAI, SSI |
| Display | - |
| LVDS | 1x 4 Lanes |
| MIPI-DSI | 1x 4 Lanes |
| Allgemein | - |
| Stromversorgung | +3.8V bis 5.5VDC |
| Leistungsaufnahme | 3W typ. |
| Betriebstemperaturbereich | -25°C - +85°C |
| Größe | 35x40mm |
| Gewicht | ~10g |
| Verfügbarkeit | 2038+ |
| PicoCore™MX93-V5I-LIN/ W11 |
