23 October 2020

PicoCoreMX8MP with NXP i.MX 8M Plus

iMX8MPlus Newsletter




NXP i.MX 8M Plus, Linux and FreeRTOS

  • NXP i.MX 8M Plus: 2x/ 4x ARM Cortex-A53@1,8GHz & Cortex-M7
    including Board Support Package and Toolchain for Bare Metal or FreeRTOS
  • Machine Learning Unit
  • Up to 8GB LPDDR4/ 512MB SLC NAND Flash or 32GB eMMC
  • Flexible Display Connection via MIPI-DSI (4 lanes) and LVDS, or MIPI-DSI and HDMI, or 2x LVDS (FullHD)
  • 3D HW acceleration: OpenGL ES 2.1/3.0/ 3.1, Video decoder 1080p60
  • High graphic performance: FullHD and 4k
  • Security Chip on Board
  • MIPI-CSI (4 lanes) and ISP in CPU
  • Audio Line IN/OUT/MIC/HEADPHONE or alternatively I2S
  • 2x USB 2.0 OTG, PCIe, 1-2x Gigabit Ethernet or alternatively RGMII
  • 2x SPI, 4x I2C, 4x Serial, 2x CAN-FD
  • I/O, PWM, 2x SDIO (SD-Card)**, RTC
  • WLAN 802.11a/b/g/n/ac +BT 5.0* and many certifications
  • Plug & Trust for IoT (NXP A71CH), I2C EEPROM*
  • Easy 5V supply
  • 0°C - +70°C, -20°C - +85°C*, -40°C - +85°C*
  • 2x100pin, 1.5mm to 3mm stacking height
  • Robust plug connector with 2x 100 pins
  • Linux Support (Yocto and Buildroot), 1-2 releases per year
  • Long-Term Available up to 2035
  • Developed and produced according to ISO 13485:2016 and ISO 9001:2015
  • Part of the pin compatible PicoCore product family

* optional **external

Samples will be available in January 2021.

To help you find the right solution, we would like to get to know your project a little better.
Send us an e-mail to or click on the button below to get early access.
We will keep you updated on the product and offer you a starterkit for a special price.
